Solution To download these drivers, download the Vision Acquisition Software (VAS) package. VAS includes NI-IMAQ, NI-IMAQdx, and NI-IMAQ I/O driver sets that serve different vision application purposes.

  1. Download latest releases of Dewesoft X software, Dewesoft X add-ons, firmware and drivers for Dewesoft data acquisition devices, technical reference manuals, user guides and brochures.
  2. Feb 02, 2021 If the camera shows up as a Generic IEEE 1394 Camera or Generic Consumer Camera, right-click on the camera and manually assign the NI-IMAQdx or Legacy IMAQ for IEEE 1394 driver. You may see a warning dialog indicating a new driver is being assigned to the device.
  3. In that case, update the driver: a. Right click the host controller and select Update driver software. Click “Browse my computer for driver software”. Click “Let me pick from a list of device drivers on my computer”. Select “1394 OHCI Compliant Host Controller”.

Windows 7 includes 1394ohci.sys, a new IEEE 1394 bus driver that is implemented by using the kernel-mode driver framework (KMDF). The 1394ohci.sys bus driver replaces the legacy IEEE bus driver in port/miniport configuration-- 1394bus.sys and ochi1394.sys.

In some situations you might want to override the default behavior of 1394ohci.sys,. You can do this by setting certain registry values that it supports.

Registry Value Locations

You can set the 1394-related registry values either globally for all 1394 controllers in the system or individually for each 1394 controller. The 1394ohci.sys, bus driver first queries the global 1394 registry values and then queries the individual 1394 controller registry values.

The following registry location contains the global 1394 registry values:

Flir

HKEY_LOCAL_MACHINESYSTEMCurrentControlSetServices1394ohci Parameters

The following registry location contains the individual 1394 controller registry values:

HKEY_LOCAL_MACHINESYSTEMCurrentControlSetControlClass {6BDD1FC1-810F-11D0-BEC7-08002BE2092F}<NNNN>

<NNNN> represents the instance identification number for each 1394 controller.

Registry Values

1394

The following table describes the registry values that the new 1394 bus driver supports. You can specify all registry values either globally or for a particular 1394 controller. Any registry values that are specified for a particular 1394 controller override any corresponding globally specified registry values.

NameTypeValueDefaultDescription
DisableGenerationCountCompareDWORD0 or 10The 1394ohci.sys bus driver compares the generation count value in the self_id register of the 1394 controller with the generation count value that is received in the asynchronous receive DMA request context buffer when it processes received asynchronous requests. Setting this value to 0 enables generation count comparison. Setting this value to 1 disables generation count comparison.
UseQuadletReadsForEnumerationDWORD0 or 10Setting this value to 0 enables the default method for retrieving the contents of the configuration ROM. Setting this value to 1 causes the new 1394 bus driver to use asynchronous quadlet read transactions to retrieve the contents of the configuration ROM.
EnumerateIP1394DWORD0 or 10Setting this value to 0 disables enumeration of IP1394 devices on the 1394 bus. Setting this value to 1 enables enumeration of IP1394 devices on the 1394 bus.
EnableGapCountOptimizationDWORD0 or 1Optimize for 1394a topology onlySetting this value to 0 disables gap count optimization. Setting this value to 1 enables gap count optimization.
Note Enabling gap count optimization improves the gap count for all 1394 bus topologies, including 1394b. The gap count value that is used is based on the table method, as specified in the IEEE-1394a specification. End-users must make sure that the gap count that is used is valid for their 1394 bus topology.
EnablePersistentCycleStartsDWORD0 or 10Setting this value to 0 disables cycle start packets if no isochronous-capable nodes are found on the 1394 bus. Setting this value to 1 enables cycle start packets regardless of whether isochronous-capable nodes are found on the 1394 bus.
Note The 1394ohci.sys bus driver disables and enables cycle start packets only if the local node is the bus manager.

Related topics

The IEEE 1394 Driver Stack
IEEE 1394 Bus Driver in Windows 7

When QuickReport or any other FLIR software that requires camera connection installs, it creates a directory in the following location: C:Program FilesFLIR SystemsFLIR Device drivers. All the drivers required for USB and Firewire cameras are in this location. They can also be found on the Software distribution CD.

Drivers flir 1394 thermal camera

Download the latest camera drivers
FLIR Device Drivers x86 (32-Bit)
FLIR Camera Device Drivers are all the drivers
for the FLIR Cameras for 32-Bit OS
Download and unzip before running the .msi file
FLIR Device Drivers x86.zip

Drivers Flir 1394 Software

FLIR Device Drivers x64 (64-bit)
FLIR Camera Device Drivers are all the drivers
for the FLIR Cameras for 64-bit OS.
Download and unzip before running the .msi file
FLIR Device Drivers x64 (64-bit)

Drivers Flir 1394 Camera

-->
