Drivers Decimator Design USB Devices

12/14/2021by admin
  1. Drivers Decimator Design Usb Devices Free
  2. Drivers Decimator Design USB Devices
April 2020
New 12G-CROSS HDMI / SDI 4K Cross Converter
MSRP US$495
(Now Shipping)
The new 12G-CROSS allows either of the HDMI or SDI outputs to be simultaneously sourced from either the HDMI or SDI input or the new 4K scaling engine. The 4K scaling engine can be driven by either the SDI or HDMI input, supports horizontal and/or vertical flipping and can be locked to either the SDI, HDMI or Genlock input.
The 12G-CROSS is a small (4.2' x 5.1' x 1.2') low power portable converter encased in a solid heavy duty aluminium case and does not contain a noisy fan. Allowing it to be used in almost any environment.
Supports 294 VESA formats via HDMI input
Decimator Design's new 4K scaling engine can scale and/or frame rate convert between 351 input formats and 57 output formats. The supported formats are:
• 294 VESA formats in via HDMI input
• (3840 or 4096) x 2160p50/59.94/60 via HDMI or 12G-SDI
• (3840 or 4096) x 2160p30/29.97/25/24/23.98 via HDMI or 6G-SDI
• (1920 or 2048) x 1080p50/59.94/60 via HDMI or 3G-SDI levels A or B
• 1920 x 1080i60/59.94/50 via HDMI or HD-SDI
• (1920 or 2048) x 1080p30/29.97/25/24/23.98 via HDMI or HD-SDI
• (1920 or 2048) x 1080psf30/29.97/25/24/23.98 via HD-SDI
• 1280 x 720p60/59.94/50/30/29.97/25 via HDMI or HD-SDI
• 1280 x 720p24/23.98 via HD-SDI
• 720 x 480p59.94 or 720 x 576p50 via HDMI
• 720 x 480i59.94 (NTSC) or 720 x 576 (PAL) via HDMI or SD-SDI
That is an amazing 20,007 possible format conversions!
The 12G-CROSS also supports 3G-SDI level A and B, allowing for conversion between both.
The 12G-CROSS is a truly portable product that incorporates an easy-to-use LCD screen and button control system. This gives easy access to the outstanding features without using complicated LED/button controls, dip switches, or having to carry around a computer to change a simple setting.
Click here to find out more
  1. Plug the Decimator into a power outlet. Plug your HDMI video source into the HDMI Input. Plug an SDI cord into any of the SDI outputs (preferably the bottom ports). Press the Enter button to wake the device if the front LCD screen is not already on.
  2. Get a USB device for which you will be writing the client driver. In most cases, you are provided with a USB device and its hardware specification. The specification describes device capabilities and the supported vendor commands. Use the specification to determine the functionality of the USB driver and the related design decisions.
Drivers Decimator Design USB DevicesDecimator softwareWindows

Drivers Decimator Design Usb Devices Free

Drivers Decimator Design USB Devices

Drivers Decimator Design USB Devices

Control either via USB on a Windows app or on-unit using the dip switch. The unit comes with a Locking DC Power Supply, HDMI Cable, USB Cable & Mounting Bracket. Warranty for all Decimator Design products is 3 years.
